700B重袋人工上袋自动封口包装机组

适用范围Scope of application

大米、杂粮、种子、饲料等行业的颗粒料人工上袋自动封口包装机组。

Rice, grains, seeds, feed and other industries granule manual bag automatic sealing packaging unit.

功能特点Funcational characteristics

1、可选配喷码机配套使用。

It can be used with optional inkjet printer

2、采用PLC+触摸屏控制,操作简单便捷。

PLC+ touch screen control, easy to operate.

3、具有多种规格配方,且能实现一键切换，快速便捷。

With a variety of specifications formula, and can achieve one-click switching,fast and convenient.

4、具有物料振实功能,不需要增加包装袋尺寸,减少包材成本。

With material vibration function, it does not need to increase the size of the packaging bag and reduce the cost of packaging materials.

5、单面覆膜和双面不覆膜编织袋均适用。

Both single-sided and double-sided non-laminated woven bags are suitable.

6、只需一人上袋即可,称量、下料、移袋、缝包等工艺流程自动化。

Only one person can load the bag,and the process of weighing,unloading,moving the bag, sewing the bag and so on is automated.

技术参数Technical parameters

1、型号：SAG-700B

Model：SAG-700B

2、包装范围(kg)：25-50

Packing range(kg)：25-50

3、包装速度(bag/h)：400-600

Packing speed(bag/h)：400-600

4、称重精度：±0.1%~±0.2%

Weighing precision：±0.1%~±0.2%

5、包装袋规格(mm)：(750~950)x(450~550)*

Bag specifications(mm)：(750~950)x(450~550)*

6、环境温度：0~40℃

Ambient temperature：0~40℃

7、电源,耗电：AC380V 50Hz,3.7KW

Power supply,power consumption：AC380V 50Hz,3.7KW

8、气源,耗气：0.5-0.7MPa,5Nm³/h

Gas source,gas consumption：0.5-0.7MPa,5Nm³/h

9、外形尺寸(mm)长X宽X高：3590x1124x3453

Overall dimension(mm)L×W×H：3590x1124x3453

-包装速度数据以大米为物料测定,具体取决于包装物料的具体特性与包装规格

The packaging speed data is measured with rice as the material,which depends on the specific characteristics and packaging specifications of the packaging material.

-包装袋尺寸可适当调整,具体咨询我司技术人员。

The size of the packing bag can be adjusted appropriately. Please consult our technicians for details.
